Wet Scrubber

The Wet Scrubber by Advance Lab is an advanced air pollution control solution designed to effectively capture and neutralize hazardous fumes and particulates. Using a high-efficiency liquid scrubbing process, it removes harmful substances from exhaust air streams, ensuring compliance with environmental safety standards. Constructed with corrosion-resistant materials, the Wet Scrubber is built to handle demanding laboratory and industrial environments.

Engineered for performance and reliability, the Wet Scrubber is customizable to suit various applications and scales. It provides a safe, efficient, and eco-friendly approach to managing toxic emissions, making it an essential component in protecting both personnel and the environment. With the Wet Scrubber, Advance Lab delivers a dependable solution for maintaining clean and compliant air quality

Features

Wet scrubbers are designed to remove water-soluble compounds from exhaust streams. Advancelab manufactures two types:

  • MiniLab® – a closed system comprising of a scrubber unit mounted above the fume hood and a holding tank below
  • MaxiLab® – a stand-alone unit that can be remotely located



MiniLab® can be utilised for individual hoods only. They allow flexibility and are convenient to install.

MaxiLab® can be used for a series of hoods and are available in two sizes for this application.

Units can be manufactured in PVC or PP sheet utilizing “hot weld” fabrication. All units come with a chemical resistant pump, sanitary and water connections and a skid tray where specified.

Parts

  1. 25mm Dia PVC Pipe
  2. Tellerette Scrubbing Media
  3. Viewing Glass (Opening for Adjusting
    the Float)
  4. 15mm Dia Incoming Water Supply
  5. Water Float
  6. Chemical Water Pump
  7. 2” Thk Mist Eliminator
  8. Opening for Changing Scrubbing Media
  9. Holding Tank
  10. Exhaust Outlet
  11. 40mm Dia Discharge with a Ball Valve
  12. PP Tray
  13. Overflow Pipe
  14.
